Product Description
1. Table size: 1120*260mm
2. Table travel 600*300mm
3. Automatic spindle feed
|
SPECIFICATION |
UNIT |
XZ6326 |
|
TABLE SIZE |
MM |
1120× 260 |
|
TABLE TRAVEL |
MM |
600× 300 |
|
SPINDLE SPEED RANGE |
R/MIN |
67-2010(V), 40-1300(H) |
|
MAX. DRILLING DIA. |
MM |
30 |
|
MAX. END MILLING WIDTH |
MM |
125 |
|
MAX. VERTICAL MILLING DIA. |
MM |
25 |
|
MAX. TAPPING DIA. |
MM |
M16 |
|
AUTOMATIC DRILLING DIA. |
MM |
14(CAST IRON) |
|
DISTANCE FROM SPINDLE NOSE TO TABLE SURFACE |
MM |
115-430 |
|
SPINDLE TRAVEL |
MM |
120 |
|
AUTOMATIC SPINDLE FEEDS |
MM/REV |
0.1, 0.15, 0.3 |
|
SPINDLE MOTOR POWER |
KW |
1.5/2.2(V), 2.2(H) |
|
OVERALL DIMENSION(L× W× H) |
MM |
1580× 1450× 2150 |
|
NET WEIGHT |
KG |
1350 |
